BGS-HDL - The dual-output

  • Thương hiệu: OPTEX-FA
  • Mã sản phẩm: OPTEX-PHOTOSENSOR
  • Tình trạng: Còn trong kho
Liên hệ
Giá sau Thuế: Liên hệ

Dual Output Version Can Replace 2 Sensors With 1


Introducing the dual-output BGS-HDL - the newest addition to
Optex FA's best-in-class lineup of height difference sensors

The newly added BGS-HDL model is equipped with two control outputs.
With support for upper and lower limit output or two-step output, applications that call for two sensors can now be covered with just a single sensor.

Two selectable distance display patterns (BGS-HDL function)

The digital panel for displaying distance on the sensor can be set to either Background mode (bcGd) or Target mode (trGt).
Select the display mode that makes seeing changes in distance easiest according to the application.

Switchable between Output 2 and Teach Input (BGS-HDL function)

For BGS-HDL, it is possible to choose from Output 2 or Teach Input by changing the setting and wiring connection (White wire).
With this function, it enables dual input operations such as “Laser OFF” or “Sample & Hold”, in addition to Teaching at the same time.

Độ chính xác lặp lại 0.01mm
Tín hiệu đầu ra NPN/PNP type Open collector Max. 100 mA/30 VDC
Voltage 12 to 24VDC
Spot size Ø0.8mm at 35mm
Thời gian phản hồi 1.5 ~ 7.5ms
Khoảng cách phát hiện Minimum Detectable Height Difference Able to detect height difference of 8µm, Reflective surfaces as well as shiny targets
